Duty cycle

Nr.

Start [s]

End [s]

Duty

Notes

1

-9

0

Power on

High voltage preparation

2

0

33

FAN 12V

Blow through (node box)

3

33

46

PM

Blow through (PM)
Restarting WiFi, each 6th cycle

4

41

42

TPH

Measuring T (average 16)
Measuring P (average 16)
Measuring H (average 4)

5

42

46

PM

Measuring PM

6

46

-

Antenna

Measuring Antenna strength (WiFi, LoRa only)

7

50

-

Gamma

Measuring Gamma

8

51

-

Report

Sending the report

9

51

300

Sleep

Idle

10

300 (0)

-

-

Go to Nr. 2
